Belangrijk!
Let op of uw huidige recorder de HD resolutie aan kan van deze camera.
Dit is geen IP camera.
Hikvision DS-2AE4225TI-D Turbo HD PTZ, 2MP, 25x zoom, IR 100mtr
Deze Hikvision PTZ kan video van hoge kwaliteit vastleggen in een omgeving met weinig licht en beschikt over een 2MP lens.
De ingebouwde CMOS-chip maakt WDR en real-time 1920 x 1080 resolutie mogelijk. Met behulp van de 25 × optische zoomlens en het IR-cutfilter biedt de camera meer details over een uitgestrekt gebied. Dankzij de ingebouwde WDR van 120dB kan de camera met alle soorten van tegenlicht omgaan.
Het zwarte anti-reflecterende glas vergroot de lichtsterkte die IR-afstand tot 100m helpt bereiken.
Deze 2MP PTZ werkt middels HD-TVI techniek maar kan ook via een schakelaar omgezet worden naar een regulier ongecomprimeerd CVBS signaal.
Specificaties:
• 1/2.8'' Progressive Scan CMOS
• 1920×1080
• 25X Optical Zoom
• WDR 120dB
• Up to 100m IR distance
• 3D intelligent positioning function
• Switchable Turbo HD and CVBS outputs
Technische Specificaties:
| Camera |
|---|
| Image Sensor: | | 1/2.8" Progressive Scan CMOS |
| Effective Pixels: | | 1920(H)x1080(V) |
| Signal System: | | PAL/NTSC |
| Minimum Illumination: | | Color: 0.05Lux@( F1.4,AGC ON); B/W: 0.005Lux@( F1.4,AGC ON), 0 Lux with IR |
| White Balance: | | Auto / Manual / ATW / Indoor / Outdoor |
| AGC: | | Auto/Manual |
| BLC: | | ON/OFF |
| WDR: | | Support |
| Shutter Time: | | 1-1/10,000s |
| Day& Night: | | ICR |
| Digital Zoom: | | 16X |
| Privacy Masking: | | 8 privacy masks programmable |
| Auto Focus: | | Auto / Semi-automatic / Manual |
| Lens |
|---|
| Focal Length: | | 4-92.0mm, 23x |
| Zoom Speed: | | Approx.3s(Optical Wide~Tele) |
| Angle of View: | | 49-2.2 degree(Wide-Tele) |
| Minimum Working Distance: | | 10~1,000mm(Wide~Tele) |
| Aperture Range: | | F1.4-F3.5 |
| Pan & Tilt |
|---|
| Pan Range: | | 360°endless |
| Pan Speed: | | Pan Manual Speed: 0.1°~80°/s, Pan Preset Speed: 80°/s |
| Tilt Range: | | -15°-90° (Auto Flip ) |
| Tilt Speed: | | Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s |
| Proportional Zoom: | | Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: | | 256 |
| Patrol: | | 8 patrols, up to 32 presets per patrol |
| Pattern: | | 4 patterns, with the total recording time not less than 10 minutes |
| Power loss recovery: | | Support |
| Park Action: | | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display: | | ON/OFF |
| Freeze Frame: | | Support |
| Infrared |
|---|
| IR irradiation distance: | | 100m |
| IR irradiation angle: | | Adjustable by zoom |
| General |
|---|
| RS-485 Protocols: | | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Menu Language: | | English |
| Power Supply: | | 12V DC |
| Power Consumption: | | Max.18W |
| Working Temperature/Humidity: | | -30 °C-65°C(-22°F-149°F)
90% or less |
| Protection Level: | | IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Mounting: | | Various mounting modes optional |
| Dimensions: | | Φ164.5(mm)×295(mm) |
| Weight (approx.): | | 2Kg (4.41Ibs) |
| Mount Option: | | Long-arm wall mount: DS-1602ZJ; Corner mount: DS-1602ZJ-corner;
Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box; Swan-neck mount: DS-1619ZJ |
